Heatilator Icon Series Wood Fireplace
The Icon is the industry’s largest wood-burning fireplace. Its beauty is highlighted by expansive viewing areas and authentic masonry looks. Let the fire roar with the Icon in the room.
- 36″, 42″ or 50″ viewing area
- Choose bi-fold or cabinet style door options
- Clean design allows finishing materials to be applied up to the firebox opening
Technical Details
ICON 100 50″ Woodburning Fireplace
| Width: | 60-5/8″ |
| Height: | 70-1/2″ |
| Depth: | 29-1/2″ |
| Rear Width: | 41-5/8″ |
| Framing Height: | 71″ |
| Framing Depth: | 30-1/2″ |
| Framing Front Width: | 61.625 |
| Framing Back Width: | 61.625 |
| Viewing Area: | 50 x 33″ |
ICON 60 36″ Woodburning Fireplace
| Width: | 44-1/2″ |
| Height: | 59-1/4″ |
| Depth: | 27-1/2″ |
| Rear Width: | 28-5/8″ |
| Framing Height: | 59-3/4″ |
| Framing Depth: | 28″ |
| Framing Front Width: | 45.5 |
| Framing Back Width: | 45.5 |
| Viewing Area: | 36 x 28-1/2″ |
ICON 80 42″ Woodburning Fireplace
| Width: | 50-1/2″ |
| Height: | 59-1/4″ |
| Depth: | 27-1/2″ |
| Rear Width: | 34-1/2″ |
| Framing Height: | 59-3/4″ |
| Framing Depth: | 28-1/2″ |
| Framing Front Width: | 51.5 |
| Framing Back Width: | 51.5 |
| Viewing Area: | 42 x 28-1/2″ |
Catalog Product Request Quote Form
Additional information
| Brand | Heatilator |
|---|---|
| Fuel Type | Wood |
| Product Type | Fireplace |
